HDPE Socket Female/Male Threaded 90° Elbow

Product Introduction

Baishunxing Pipe Industry The HDPE Socket Female/Male Threaded 90° Elbow is a high-performance fitting that integrates directional change and transition functions. One end features a standard socket for thermal fusion welding with HDPE pipes, while the other end is a 90-degree female or male threaded interface (female threads are often reinforced with a brass insert). This design allows the piping system to make a precise right-angle turn while providing a direct and secure connection to metal valves, faucets, instruments, or pumps.

Features

Precision 90° Geometry: Optimized internal flow path minimizes hydraulic resistance and reduces pressure loss as fluid passes through the elbow.

Metal Reinforcement (Female version): Features a high-grade brass insert in the threaded section to enhance mechanical strength, preventing cracking or stripping from over-tightening.

Heavy-Duty Wall Thickness: The elbow section is specially reinforced to withstand high system pressure and water hammer effects.

Full-Bore Flow: Smooth internal channel with no diameter reduction ensures maximum flow rate and prevents sediment accumulation.

Advantages

Space-Saving Layout: Combines directional change and transition into one fitting, significantly saving installation space in confined areas such as inside walls or equipment boxes.

Superior Sealing Performance: Socket fusion provides a molecular-level bond, while precision threads ensure long-term airtightness when interfacing with metal components.

Ultimate Corrosion Resistance: The HDPE body withstands diverse chemical media, and the metal insert resists dezincification, ensuring a service life of over 50 years.

Easy Maintenance: The threaded end allows for equipment removal and replacement without damaging the piping system, making it ideal for future maintenance.

Applications

Domestic Water Terminals: Used for right-angle transitions in wall-mounted plumbing to connect washbasins, showers, or outdoor metal faucets.

Industrial Equipment Integration: Connecting HDPE lines at a 90-degree angle to pump inlets/outlets or pressure tanks in compact pump rooms or filtration systems.

Agricultural Sprinkler Systems: Connecting upright sprinklers or solenoid valves, especially useful for branch points requiring a compact layout.

Plumbing Retrofitting: Serving as a key component for making 90-degree connections between new HDPE pipes and existing metal plumbing during renovations.
